Lungalargaluce Extreme LED ATEX Z2

High performance emergency lighting fixture with excellent mechanical strength ( IK09 ). Lungalargaluce EXTREME is designed to answer high risk application requirements. In the industrial context, it’s perfect for installations in explosive atmosphere spaces created by alteration in gassy substances and the presence of air suspended combustible powder (pursuant to ATEX 2014/34/EU regulation for zone 02 and 22). Optics can be exchanged to cover different kind of applications (escape routes, antipanic, light spot) , different zones, different installation high from 3m to 7m. Lighting performance are the highest on the market thanks of the OPTICS design and thanks to the high efficiency LED used. Fixture lumen flux is 1000lm.

Power Supply 230Vac ± 10% 50Hz
Operation Mantained (SA), not Mantained (SE)
Standard EN 60598-1, EN 60598-2-2, EN 60598-2-22, EN 1838, EN 50172, ATEX 2014/34/EU
ATEX Classification :
CE EX II 3G Ex nA IIB T4 Gc
CE EX II 3D Ex tc IIIC T80°C Dc
Protection grade IP65, IK09
Autonomy 1h, 1,5h, 2h, 3h, 8h
Working temp. -20°C ÷ +50°C (Titanium battery)
Mounting ceiling, wall, recessed
Housing Die-cast aluminium
Optics lenses in highly transparent PMMA - 5 differet in the set
Light Source LED
