Dimensions (L x W x H): 55 x 78 x 120 mm
Mains power supply: 230 – 240 V / 50 Hz
Sensor Technology: passive infrared
Application, place: Outdoors
Mounting height: 1,80 – 4,00 m
Optimum mounting height: 2 m
Detection angle: 180 °
Angle of aperture: 90 °
Sneak-by guard: Yes
Capability of masking out individual segments: Yes
Reach, radial: r = 1.5 m (4 m²) / r = 3 m (14 m²)
Reach, tangential: r = 5 m (39 m²) / r = 12 m (226 m²)
Twilight setting: 2 – 2000 lx
Time setting: 10 s – 15 Min.
Output: 2000 W
Settings via Potentiometers
Interconnection: Yes
IP-rating: IP54
Ambient temperature: -20 – 50 °C
