Key Features
10.1" responsive HD color touchscreen display
Ultra-fast quad-core CPU for instant response
Home Assistant Integration
Wall-mount design compatible with EU standard switch boxes
Integrated dual 2W high-quality stereo speakers
Bluetooth and SONOS speakers support
Dual connectivity: Bluetooth 5.4 and Dual Band Wi-Fi 6 (2.4GHz & 5GHz)
Built-in relay controlling appliances up to 1500W
4 customizable buttons for quick actions & scenes
Built-in proximity & brightness (lux) sensors
Power monitoring function of connected Shelly PM devices
Fully customizable screen interface for device management
Integrated media player & internet radio support
Size (HxWxD): 155,8x272,5x38,3 mm / 6.13x10.7x1.50 inch
Weight: 920 g / 32.45 oz
Touch Screen: 5-point capacity screen, G+FF touch
Screen resolution: 1280x752 px
Screw terminals max torque: 0.4 Nm / 3.5 lbin
Conductor cross section: 0.75 to 2.5 mm² / 18 to 14 AWG (solid, stranded, and bootlace ferrules)
Conductor stripped length: 15 mm / 0.24 to 0.59 in
Mounting: Wall box
Shell material: Metal stamping, PC with coating, glass
Speaker: 2x 2 W (BOX sound cavity)
Environmental - Ambient working temperature: -20 °C to 40 °C / -5 °F to 105 °F
Humidity: 30 % to 70 % RH
Power supply: 100 - 240 V~ 50/60Hz
Power consumption: < 15 W
USB TYPE-C power supply: 5 V⎓ / 3 A
Power Button: 1 button for turning On/Off the screen
Control Buttons: 4 functional buttons for setting
Output circuits ratings Max. switching voltage: 240 V~
Max. switching current: 5 A
Output (AC) 100 - 240 V~ 50/60Hz
Output (USB TYPE-C) : 5 V⎓ / 0.5 A
Sensors, meters
Internal-temperature sensor: No
Ambient temperature sensor: No
Humidity sensor: No
Light sensor: Yes
Microphone: Yes (Four-microphone line array)
Proximity sensor: Yes (≤1 meter)
Radio Wi-Fi - Protocol: Wi-Fi 6 Dual Band
RF band: 2.4 & 5 GHz, Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol: 5.4
RF band: 2402 - 2480 MHz, Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
Microcontroller unit CPU: Rockchip RK3566 Quad core Cortex-A9
RAM: 2 GB, Flash: 16 GB
System: Android 11
Firmware capabilities - Schedules: 20
Webhooks (URL actions): 20 with 5 URLs per hook…
Scripting: No
MQTT: Yes
| Code | Description | Price | Price+VAT | Unit | ||
|---|---|---|---|---|---|---|
|
3800238073008 |
Shelly Wall Display XL Black |
€370.00
€314.50 |
-15%
€389.98 |
tk |
