Dimensions (L x W x H): 87 x 78 x 110 mm
Mains power supply: 230 – 240 V / 50 Hz
Sensor Technology: passive infrared
Application, place: Outdoors, Indoors
Mounting height: 1,80 – 3,00 m
Optimum mounting height: 2 m
Detection angle: 130 °
Angle of aperture: 40 °
Sneak-by guard: Yes
Capability of masking out individual segments: Yes
Reach, radial: r = 3 m (10 m²)
Reach, tangential: r = 12 m (163 m²)
Twilight setting: 2 – 2000 lx
Time setting: 8 s – 35 Min.
Output: 600 W
Settings via Potentiometers
Interconnection: Yes
IP-rating: IP54
Material: Plastic
Ambient temperature: -20 – 50 °C
Sensor Technology: Passive infrared
