Dimensions (L x W x H): 65 x 95 x 95 mm
Mains power supply: 220 – 240 V / 50 – 60 Hz
Sensor Technology: passive infrared
Application, place: Outdoors, Indoors
Mounting height: 1,80 – 2,50 m
Optimum mounting height: 2 m
Detection angle: 180 °
Angle of aperture: 90 °
Sneak-by guard: Yes
Capability of masking out individual segments: Yes
Reach, radial: r = 3 m (14 m²) / r = 4 m (25 m²)
Reach, tangential: r = 6 m (57 m²) / r = 20 m (628 m²)
Twilight setting TEACH: Yes
Twilight setting: 2 – 1000 lx
Time setting: 5 s – 15 Min.
Output: 2000 W
Functions: Normal / test mode, Manual ON / ON-OFF
Settings via: Remote control,Potentiometers,Smart Remote
Interconnection: Yes
IP-rating: IP54
Ambient temperature: -20 – 50 °C
