Type: Motion detector
Dimensions (Ø x H): 78 x 89 mm
Mains power supply: 230 – 240 V / 50 – 60 Hz
Sensor Technology: passive infrared
Application, place: Outdoors, Indoors
Installation: In-ceiling installation
Mounting height: 2,50 – 4,00 m Optimum 2,5m
Detection angle: 360 °
Angle of aperture: 90 °
Sneak-by guard: Yes
Capability of masking out individual segments: Yes
Reach, radial: Ø 4 m (13 m²)
Reach, tangential: Ø 8 m (50 m²)
Twilight setting: 2 – 2000 lx
Time setting: 8 s – 35 Min.
Output: 1000 W
Settings via Potentiometers
Interconnection: Yes
IP-rating: IP54
Material: Plastic
Ambient temperature: -20 – 40 °C
