Dimensions (L x W x H): 73 x 78 x 113 mm
Mains power supply: 230 – 240 V / 50 Hz
Sensor Technology: passive infrared
Application, place: Outdoors, Indoors
Mounting height: 1,80 – 3,00 m
Optimum mounting height: 2 m
Detection angle: 160 °
Angle of aperture: 40 °
Capability of masking out individual segments: Yes
Reach, radial: r = 3 m (13 m²)
Reach, tangential: r = 12 m (201 m²)
Twilight setting: 2 – 2000 lx
Time setting: 8 s – 35 Min.
Output: 600 W
Settings via Potentiometers
Interconnection: Yes
IP-rating: IP54
Ambient temperature: -20 – 50 °C
Sensor Technology: Passive infrared
